Scanstrut LMB-A2 Self Leveling Radar Mount, Backstay (Aft), For SITEX/Simrad/Furuno Domes
Maximize your Radar's performance
2.6m (8’6”) high, mounts forward of the
backstay, keeping your radar away from any interference, leaving a clear deck
free from obstruction.
Constructed from the best marine-grade aluminium,
designed to fit the most up to date radars from Furuno.
Product Information.
Hydraulic damping
The main levelling unit features a fine-tuned damping system which reacts to
major changes in heel angle of the boat. It is entirely maintenance-free and no
power is required.
Bespoke mounting pole
2.6m (8’6”) aluminium mounting pole, supplied in 2 lengths with hidden joiner
piece. Cables are routed down a cable channel for a neat install. Extension
pieces are available.
High strength universal
base for mounting pole
Eliminates loading on backstay. The base can be deck, transom or chainplate
mounted.
Suitable for any yacht
Stainless radome cradle has a fine tune adjustment for backstay angle and the
product can be installed on both adjustable and split backstays (see faq for
further information).
Nylon backstay bushing
supplied
Clamps around backstay allowing cable tension to be adjusted.
Mount your radar higher
Additional 0.6m and 1.3m lengths available to mount your radome higher
Devices Compatible with LMB-A2 Self Levelling Radar Mount - Backstay
-
Furuno
-
1621
-
1622
-
1623
-
1715
-
1724
-
1734
-
1815
-
1824
-
1832
-
1834
-
1835
-
DRS2D
-
DRS42DL
-
DRS42DL+
-
DRS4D / DRS4D-NXT
-
DRS4W
-
NavNet (18")
-
NavNet (24")
-
Interphase
-
Mini RE-1
-
RE-8
-
RE-9
-
JRC
-
1000, 1000mk2
-
1066
-
1500, 1500mk2
-
Koden
-
2kW 12"
-
4kW [RB715A]
-
Lowrance
-
LRA-1800 / RB714A / DX42
-
Navman
-
8000 Series [8084/8120] 18"
-
Northstar
-
M series/8000i (18")
-
Simrad
-
GB40 / NX40/45 / NSE8/12 / RB712A / DX42S
-
Sitex
-
MDS -1
-
MDS -8
-
MDS -9
-
MDS-12
-
NKE-1066
-
Techmarine
-
T-72.01
-
T-72.02
-
T-72.04
|
