Ruggedised, High Definition, Day and Night network bullet video camera
suitable for all above deck applications. Integrated sun-cover for maximum
visibility and small frame size for easy installation anywhere on the boat.
| |
GENERAL SPECIFICATIONS |
System
|
| CPU |
32-bit ARM9 RISC CPU up to 432MHz |
| Flash / SDRAM |
128MB / 128MB |
Camera
|
| Image Sensor |
2.0 Megapixel 1/2.8" SONY progressive scan CMOS(Exmor) |
| Total Pixels |
1952(H) x 1116(V) 2.18 Megapixel |
| Effective Pixels |
1944(H) x 1104(V) 2.15 Megapixel |
| S/N Ratio |
More than 50dB |
| Minimum Illumination |
0Lux (IR On) |
| IR Distance |
20m |
| Day & Night |
ICR |
| Lens |
6.0mm Megapixel Board Lens |
| Field of View |
Diagonal = 63.6 deg +/- 3 deg
Horizontal = 33.1 deg +/- 3 deg
Vertical = 53.3 deg +/- 3 deg |
Video
|
| Video Compression |
H.264 High Profile@4.0, MJPEG –Image quality: 3 Steps |
| Resolution |
Up to 1920 x 1080 (Full HD) |
| Frame Rate |
H.264 Up to 30fps with 1920x1080 | MJPEG Up to 30fps with VGA resolution |
| Video Streaming |
Support multi stream with H.264, MJPEG
Adjustable frame rate
CVBR/CBR in H.264 |
| Image Setting |
Day & Night
Auto White Balance
Auto Exposure
Privacy Mask
Effects - Colour, Sharpness, Mirror / V-Flip |
System Integration
|
| Security |
Password protection, User access log, HTTPS encryption |
| Supported Protocol |
HTTP, HTTPS, FTP, SMTP, UPnP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, ICMP,
DHCP |
| Intelligent Video |
Motion detection up to 1920x1080 with 4x3 blocks |
Physical
|
| Power Source |
DC12V/1.5A, PoE(Power over Ethernet): 802.3af |
| Power Consumption |
Max. 3.3W, Max. 5.3W with IR |
| Net Weight |
900g |
| LED's |
Power, Network Connection |
| Dimensions |
83.8mm(W) x 155mm(H) x 178.1mm(D) including Bracket |
| General Operation Temperature |
0 degree~40 degree Celsius(32F~104F) |
| Storage Temperature |
-10 degree~50 degree Celsius(14F~122F) |
